Features

Crane base suitable for installation with incorporated sub-base, for direct welding to the sub-base and longitudinal crane folding position. Extra hydraulic extendable outriggers with max spread of 32' 8". Outrigger rams have jointed plate in Monocast material and hoses fitted inside the outrigger lateral extension supports. 360° continuous rotation by means of double hydraulic motor, complete with hydraulic and electric rotation joints. Rotation torque: 95595 lbs.ft Hydraulic PROLINK system (Progressive Link up to 10° above the horizontal position). Linkage on crane articulations, maintaining a constant lifting moment and better crane performances in terms of both dynamic lifting and static capacity. Remote control of the crane and outriggers via 6 linear functions digital Fassi RCH or RCS radio. Radio remote control handle with graphic display showing information of the crane working status and icons to select the available functions, visual and acoustic indicators of the load percentage capacity applied on the crane (crane and outriggers manual control only in case of emergency). Version with double hydraulic circuit composed by n. 2 D900 proportional digital multifunction distributor banks for crane control positioned on the column and completed with digital electro-hydraulic modules, n. 2 filters on their pressure lines and double return line. Standard segments composition of the distributor banks: 1st distributor bank: rotation, inner boom lift ram and, if installed, jib extension rams and winch. 2nd distributor bank: outer boom lift ram, crane extension rams and, if installed, jib lift ram and extra function. Multifunction ability of the distributor bank managed by the dynamic software "Flow Sharing". Hydraulic proportional distributor bank, five functions, for outriggers control. FX900 electronic lifting moment limiting device monitoring the pressure induced by the load in all the lifting rams, complete with 7" graphic color touch screen display located on the crane base, giving analytic information about the working status of the crane and outriggers. XP device (Extra Power) to activate, in case of problematic working situations, an extra power reducing the working speed. IMC (Integral Machine Control) and ADC (Automatic Dynamic Control) systems integrated in the electronic of FX900 , to manage the digital communication among the electronic devices and the automatic control of the dynamic (crane working speed depends by the entity of the load applied). MPES system (Multi Power Extension System) that guarantees an exceptional extension/retraction speed of the extension booms, built up by a set of equally powerful independent rams, linked in series connection and activate by a single control. Special independent fixing system of the extension rams to guarantee high vertical lifting performances. Extension booms guide shoes with "forced" assembly to reduce vertical and lateral clearance, ensuring greater durability. Special guide shoes material with high sliding degree and low greasing request. Oil recycling valve having the function to double the speed of the extension booms exit, electrically operating and activated through selection from the radio remote control handle. XF type safety check valves on the lifting rams, to assure maximum check, precision and fluidity of the crane movements. 2 oil coolers type 120/24 (24V) with soft-start function to eliminate the peaks of current during the ignition, brushless motor having fully integrated motor control electronics certified according to IP68 protection level, automatic self-cleaning function thanks to the completely reversible fan motor rotation and temperature sensor to read and show the oil temperature level on the user panel display and activate the oil coiler to the temperature fixed in the Fassi software. Carbon look carters for hydraulic and electric circuit, crane and outriggers controls, motoreducers, column and inner boom sides protection, more captivating from an aesthetical pointof view and resistant. 66 gals steel oil tank. 66138 lbs boom tip swivel hook.

Included options

12 V electric feeding Opposite levers control sequence Hydraulically tilt able outriggers Outrigger rams Hydraulically tilt able outrigger for supplementary outriggers Hydraulic extension type "L616L" Manual telescopic extension type "RL61" 2 activated functions 6 functions V7S radio remote control Extra for radio remote control with color display Two working zones lifting moment limiting device Dinitrol application IE742 feeding box Work light control function JDP (Jib Dual Power) device activation 2 work lights mounted on outer boom 2 work lights mounted on hydraulic jib Orange LED marker lights for crane outrigger Orange LED marker lights for supplementary outriggers FSC/SII Fassi Stability Control System Extra for rotating electric joint with 21 rings Total integrated sub - frame
