Features

The E-HPLS and the enormous reach opens up a wide range of applications. More efficiency with fly jib due to DPS Plus Perfect appearance and the highest value retention due to coating technology Additional applications with Power Link Plus Increased operating times due to low-maintenance extension system High operator friendliness thanks to optional radio remote control Technical Specifications: Max. lifting moment: 179950.0 ft-lbs. Max. lifting capacity: 19620 lbs. Max. hydraulic outreach: 69' 11" Max. manual outreach: 76' 5" Max. outreach (with fly jib): 96' 5" Slewing torque with 1 gear: 20260.0 ft-lbs. Stabilizer spread (std): 16' 5" Fitting space required (std): 3' 2" Width folded: 8' 3" Max. operating pressure: 5075 psi Pump capacity: 19.8 to 26.4 US gal./min Dead weight (std): 5690 lbs.

Included Options

• 18’ x 102” Heavy Duty flatbed body • 1-1/8” Apitong Hardwood Decking • Structural steel channel cross members on 12” centers • 6” x 8.2# channel side and end rails • Expanded side rails to 102” • Approx. 36” tall tread plate header • LED work lights mounted on header & switched in cab • Tool holders mounted on front of header • Qty.4 sliding strap winches w/straps & tie down bar. Installed curbside • Qty.2 frame mounted, steel 48” x 18” x 18” underbody toolboxes w/plywood floor • Qty.2 access ladders @ front of body w/grab handles on header • LED marker lights • Heavy duty ICC bumper w/access steps • Mudflaps • Painted Black • Complete installation behind crane • Ecco 12-20003-E 60” Vantage Lightbar mounted on cab w/in cab controller
