New Stellar SI-60-174IO

Stock # HL-3055

Contact For Price/Rate

Request a quote

Features and Options


Hoist rated capacity 60,000 lbs Main frame 8” x 4” x 1/2” A500 C tubing Sub frame 4” x 2” x 1/4” A500 C tubing Front stop 1-1/2” plate Container lock Automatic spring loaded Lift cylinder shaft 2-1/2” plate Rear hinge shaft 3” solid steel Cable 7/8” (6 x 37 EXIWRC) Cable sheaves 10” O.D. bronze-bushed sheave Cable anchor 4 cable clamps Cable end Steel casting Rear hold down 1” plate located for std. containers Middle hold down 3/4” plate Lift cylinders 6” x 72” D.A. Reeving cylinders 7” x 80” D.A. Direct mount pump Gear types 35 gpm @ 1500 rpm Operating pressure 1850 psi Hydraulic valve 2 spool 45 gpm safety bypass Hydraulic reservoir 60 gal. 25 micron filter & screen filter Outside rollers 4” O.D. with bronze bearing Inside rollers 6” O.D. hardened roller & pins Working points Greaseable Safety stand Factory installed I.C.C. Bumper Folding, mounting lugs factory installed Rear bumper Pre-drilled bolt mount-sealed beam backup, clearance and tail lights

Included options

• Stellar SI60-174ORR Cable Hoist Assembly-Outside Rail, Reverse Mount Lift Cylinders, 60,000 lb Capacity, Designed to Handle 18"-22' Long Containers • Standard Black Paint • 2 Section Air Controller Pedestal for Use w/ Cable Hoists • 60 Gallon Reservoir and 2 Section Valve Bank Assembly • Direct mount bi-rotational, 7/8" shaft, 13 spline, SAE "B" gear type hydraulic pump • Standard Bumper Assembly for use w/ Folding ICC Bumper • Auto Folding ICC Bumper for Use with Standard Bumper Assembly • Tandem Axle Steel Fender Assemblies with Mounting Brackets. For Stellar Cable Hoist Only • Roll-Rite DC400 Automatic Roll-Off Tarp System with Single- Stage Telescopic Gantry for Tandem Axle Chassis Applications, Up to 24’ Long Containers, Gantry Raises 5’ to 8’, 12V Self-Contained Electric/Hydraulic Power Unit with Wireless Controls for Extend and Retract of the Tarp, Torsion Springs for Arms, Heavy Duty Mesh Tarp.

Product Specs

  • Location : Kansas City, KS
  • Ton-Meters : 0
  • Ton Rating: 30
  • Type : Cable Hoists
